Maintain and repair services are still available
For over 30 years, IWG has been a proud supplier of water treatment technology. NPS-A4 is among the extensive list of components that led effectively to IWG’s success.
The NPS-A4 retains the advances in functionality achieved by the NPS-A3, but without the integral carbon filter.
The NPS-A4 incorporates a modular design, allowing many water system product configurations to be developed from common building blocks. Its self-monitoring system scans for a range of fault conditions, which can be reported to a cabin management system through industry-standard data protocols.
The NPS-A4 system uses a powerful microprocessor to analyze the monitoring system and provide instant feedback to users concerning the functionality of the unit.
| Dry Weight | 6.2 lbs (2.8 Kg) with support plate; Contains 1.3 lbs of water |
|---|---|
| Input Voltage | 28 VDC. Optional: 115 VAC/400 Hz |
| Voltage | (Reversal protection); To meet RTCA DO-160D |
| Input Current | 1.0 A nominal (1.2 A initial surge) or 0.3 A max at 115 VAC |
| Max Flow | 1USFPM (3.8 LPM) |
| Weight | 6.2 lbs (2.8 Kg) |
| Dimensions | 11.6 high x 6.3 wide x 4.0 deep (267 x 159 x 102 mm) |
Potable Water Treatment Unit
UV-C LED treatment component for point-of-use applications — lightweight, low power, simple to install.
Potable Water Treatment Unit
Current standard on many high-end business jets, with enhanced control and monitoring.
Potable Water Treatment Unit
IWG-series treatment unit with integrated control and monitoring.
